IFM IF5579 Inductive sensor Malaysia
- Very high switching frequency
- High protection rating for the requirements of harsh industrial environments
- Wide operating temperature range
- Robust metal housing for use in harsh industrial environments
-
For a precise position detection on machines
Product characteristics
Electrical design PNP Output function normally open Sensing range[mm] 4 Housing threaded type Dimensions[mm] M12 x 1 / L = 80 Application
Special feature Gold-plated contacts Electrical data
Operating voltage[V] 10...30 DC Current consumption[mA] 10 Protection class III Reverse polarity protection yes Outputs
Electrical design PNP Output function normally open Max. voltage drop switching output DC[V] 2.5 Permanent current rating of switching output DC[mA] 200 Switching frequency DC[Hz] 400 Short-circuit protection yes Overload protection yes
