Festo HEE-D-MAXI-24 On/Off Valve Malaysia
Technical Data
- DesignPiston gate valve
- Type of actuationElectric
- Sealing principleSoft
- Exhaust-air functionWithout flow control option
- Manual overrideDetenting
- Type of resetMechanical spring
- Type of pilotingPilot actuated
- Symbol00991008
- Valve function3/2-way, closed, monostable
- Operating pressure0.25 MPa ... 1.6 MPa
- Operating pressure2.5 bar ... 16 bar
- lapOverlap
- Duty cycle100%
- Characteristic coil data24 V DC: 2.5 W
- Permissible voltage fluctuations+/- 10 %
- Operating mediumCompressed air to ISO 8573-1:2010 [7:4:4] Inert gases
- Note on operating and pilot mediumLubricated operation possible (in which case lubricated operation will always be required)
- Corrosion resistance class CRC2 - Moderate corrosion stress
- Note on materialsRoHS-compliant
- LABS (PWIS) conformityVDMA24364-B1/B2-L
- Media temperature-10 °C ... 60 °C
- Ambient temperature-10 °C ... 60 °C
- Type of mountingIn-line installation With accessories
- Mounting positionoptional
- Flow directionNon-reversible
- Product weight800 g
- Pneumatic connection, port 3G3/8
- Air purity class at outputCompressed air to ISO 8573-1:2010 [7:4:4] Inert gases
- Electrical connectionType C Plugs To DIN EN 175301-803
- Signal status displayWith accessories
- Material sealsNBR
- Material housingDie-cast aluminium
