-Accurate and quick response to changes in flow demand and line pressure variations
-Balanced valve minimizes effect of changes in inlet pressure on outlet pressure
-Standard relieving models allow reduction of outlet pressure even when the system is dead-ended
-Full flow gauge ports
-Low torque, non-rising adjusting knob
-Integral locking device on knob adjustment
-Can be serviced without removal from the air line

Technical Details

Medium	Compressed air
Operating Temperature	-34 ... 80 °C, -29 ... 176 °F
Port Size	G1
Gauge Port	Rc1/4
Adjustment	Knob
Maximum Inlet Pressure	20 bar, 290 psi
Outlet Pressure Adjustment	0.3 ... 8.5 bar, 4 ... 125 psi
Relieving / Non Relieving	Relieving
Flow	227 dm3/sec, 481 scfm
Materials - Adjusting Knob	Acetal
Materials - Body	Aluminium alloy
Materials - Bonnet	Aluminium alloy
Materials - Elastomers	Nitrile rubber (NBR)
Country of Origin	Mexico
Range	R17
Brand	IMI Norgren
