-High flow rate
-Damped operation
-Clear compact design
-Solenoid interchangeable without tools (Click-on®)
-Particularly suitable for use as water valve in accordance with DIN EN 60730-2-8

Technical Details

Medium	Gases, Liquids
Operating Temperature	-10 ... 50 °C, 14 ... 122 °F
Operating Pressure	0.1 ... 16 bar, 1.45 ... 232 psi
Port Size	G3/8
Actuation	Solenoid pilot / Spring return
Coil Code	9101
Function	NC
Nominal Diameter	10 mm
Valve operation	2/2
CV Body	3.5 cv
Flow	50 l/m, 1.8 scfm
Materials - Body	Brass
Materials - Elastomers	Nitrile rubber (NBR)
Certification - IP Rating	IP65
Dimensions - Height	44 mm
Dimensions - Length	78.5 mm
Dimensions - Width	60 mm
Weight	0.44 kg
Country of Origin	Germany, United States
Range	82400
Brand	IMI Buschjost
