-High flow rate
-Simple T - spool design with soft sealing
-Highly reliable, long life, low maintenance
-Easily interchangeable solenoid system including Ex approved coils

Technical Details

Medium	Compressed air
Operating Temperature	-10 ... 50 °C, 14 ... 122 °F
Operating Pressure	1 ... 10 bar, 15 ... 145 psi
Port Size	G1/4
Actuation	Solenoid pilot / Air spring return
Function	NC
Valve operation	3/2
Flow	1325 l/m, 47 scfm
Materials - Body	Aluminium
Materials - Elastomers	Nitrile rubber (NBR)
Materials - Seals	Nitrile rubber (NBR)
Dimensions - Height	30 mm
Dimensions - Length	115.6 mm
Dimensions - Width	55 mm
Weight	0.28 kg
Country of Origin	Germany
Range	26230
Series	80107 Inline Valve
Brand	IMI Herion
