-Gold-plated contacts
-High cycle life
-Vibration resistant to 15 g
-Microswitch approved by UL and CSA
-Intrinsically safe operation
-Direct interface to Excelon air line units

Technical Details

Medium	Gases, Liquids
Operating Temperature	-25 ... 80 °C, -13 ... 176 °F
Operating Pressure	5 ... 420 bar, 72 ... 6091 psi
Port Size	G1/4
Materials - Body	Aluminium
Materials - Seals	Polytetrafluoroethylene (PTFE), Nitrile rubber (NBR)
Certification - IP Rating	IP65
Dimensions - Height	87.5 mm
Dimensions - Length	30 mm
Dimensions - Width	30 mm
Weight	0.1 kg
Country of Origin	Czechia, Germany
Range	18D Hydraulic
Series	18D
Brand	IMI Herion
