-Gold-plated contacts
-High cycle life
-Vibration resistant to 15 g
-Microswitch approved by UL and CSA
-Intrinsically safe operation
-Direct interface to Excelon air line units

Technical Details

Medium	Gases, Liquids
Operating Temperature	-10 ... 80 °C, 14 ... 176 °F
Operating Pressure	-1 ... 30 bar, -14.5 ... 435 psi
Port Size	Flange
Materials - Body	Aluminium
Materials - Seals	Nitrile rubber (NBR)
Certification - IP Rating	IP65
Dimensions - Height	87.5 mm
Dimensions - Length	30 mm
Dimensions - Width	30 mm
Weight	0.22 kg
Country of Origin	Czechia, Germany
Range	18D Pneumatic
Series	18D
Brand	IMI Herion
