-Gold-plated contacts
-High cycle life
-Vibration resistant to 15 g
-Microswitch approved by UL and CSA
-Intrinsically safe operation
-Direct interface to Excelon air line units

Technical Details

Medium	Gases, Liquids
Operating Temperature	0 ... 50 °C, 32 ... 122 °F
Operating Pressure	-1 ... 30 bar, -14.5 ... 435 psi
Port Size	G1/4
Materials - Body	Aluminium
Materials - Seals	Fluoro-Polymer-Material (FPM)
Certification - IP Rating	IP65
Dimensions - Height	87.5 mm
Dimensions - Length	30 mm
Dimensions - Width	30 mm
Weight	0.22 kg
Country of Origin	Czechia, Germany
Range	18D ATEX Pneumatic
Series	18D
Brand	IMI Herion
