-Can be installed at any point in the compressed air system without regard to accessibility – can be installed in the most convenient location for application

Technical Details

Medium	Compressed air
Operating Temperature	-20 ... 80 °C, -4 ... 176 °F
Port Size	G1
Gauge Port	Rc1/8
Adjustment	Air pilot operated
Maximum Inlet Pressure	20 bar, 290 psi
Outlet Pressure Adjustment	0.3 ... 19 bar, 4 ... 275 psi
Relieving / Non Relieving	Relieving
Flow	180 dm3/sec, 381 scfm
Materials - Body	Zinc alloy
Materials - Bonnet	Aluminium alloy
Materials - Elastomers	Nitrile rubber (NBR)
Dimensions - Height	125 mm
Dimensions - Length	106 mm
Dimensions - Width	125 mm
Weight	2.1 kg
Country of Origin	Mexico
Range	11-808
Brand	IMI Norgren
