Bussmann 170M6116 Fuse Malaysia
General specifications
| Product Name |
Eaton Bussmann series high speed square body fuse
|
| Catalog Number |
170M6116
|
| UPC |
051712262866
|
| EAN |
5996516017791
|
| Product Length/Depth |
168 mm
|
| Product Height |
76 mm
|
| Product Width |
95 mm
|
| Product Weight |
924 g
|
| Compliances |
CE Marked
RoHS Compliant |
| Certifications |
UL Recognized
IEC Rated |
Electrical data
| Amperage Rating |
1250 A
|
| Voltage rating |
690 V (IEC), 700 V (UL)
|
| Voltage type |
AC
|
| Clearing (I2T) |
1950000 at 660 V
|
| Pre arc (I2T) |
290000
|
| Watt losses |
140 W
|
| Breaking capacity |
200 kA
|
| Class |
Class aR
|
Product specification
| Fuse size |
3
|
