Delta VFD075C53A-21 C2000 Series Drive Malaysia
SPECIFICATIONS
| Model Name | VFD075C53A-21 |
| Series | C2000 |
| Input Voltage – Phase | 575 V – 3 Phase |
| Horsepower – Kilowatts | 10 HP – 7.5 KW |
| Light Duty* Amps | 12.1 A |
| Normal Duty** Amps : | 10 A |
| Heavy Duty*** Amps : | 8.3 A |
| Frame Size | B |
| IP Rating | IP 20 |
| Built In EMC Filter | No |
| Built In Braking Chopper | Yes |
| Built In DC Reactor | No |
| Built In CANopen Card | No |
| Weight | 10.56 Lbs |
| Dimensions | 7.48 (in) x 12.6 (in) x 7.48 (in) |
* Light duty: 120% of rated current for 1 minute every 5 minutes
** Normal duty: 120% of rated current for 1 minute every 5 minutes; 160% for 3 seconds every 30 seconds
*** Heavy duty: 150% of rated current for 1 minute every 5 minutes; 180% for 3 seconds every 30 seconds
