Festo LFR-1/2-D-MIDI 159584 Filter Regulator Malaysia
TECHNICAL DATA
- SizeMidi
- SeriesD
- Actuator lockRotary knob with detent
- Mounting positionVertical +/- 5°
- Grade of filtration40 µm
- Condensate drainManually rotating
- Structural designFilter regulator with pressure gauge
- Max. condensate volume43 ml
- Bowl guardMetal bowl guard
- Symbol00991585
- Pressure gaugewith pressure gauge
- Operating pressure0.1 MPa ... 1.6 MPa
- Operating pressure1 bar ... 16 bar
- Pressure regulation range0.5 bar ... 12 bar
- Max. pressure hysteresis0.2 bar
- Standard nominal flow rate3400 l/min
- Operating mediumCompressed air as per ISO 8573-1:2010 [-:9:-] Inert gas
- Information on operating and pilot mediaOperation with oil lubrication possible (required for further use)
