Model No. Identification
R7ML Series
|
MODEL |
FUNCTION |
POWER / I/O CONNECTION |
|
BASIC MODULE |
R7ML-DA16 |
16-point contact input (NPN/PNP) |
M3 screw terminal |
|
R7ML-DC16A |
16-point transistor output (NPN) |
M3 screw terminal |
|
R7ML-DC16B |
16-point transistor output (PNP) |
M3 screw terminal |
|
R7ML-DC16D |
16-point transistor output (PNP, shortcircuit protection) |
M3 screw terminal |
|
R7ML-SV4 |
4-point DC voltage/current input (isolated) |
M3 screw terminal |
|
R7ML-TS4 |
4-point thermocouple input (isolated) |
M3 screw terminal |
|
R7ML-RS4 |
4-point RTD input (isolated) |
M3 screw terminal |
|
R7ML-LC2 |
2-point high speed strain gauge input (isolated) |
M3 screw terminal |
|
R7ML-YV2 |
2-point DC voltage output (isolated) |
M3 screw terminal |
|
R7ML-YS2 |
2-point DC current output (isolated) |
M3 screw terminal |
|
EXTENSION MODULE |
R7ML-EA8 |
8-point extension contact input (NPN/PNP) |
M3 screw terminal |
|
R7ML-EA16 |
16-point extension contact input (NPN/PNP) |
M3 screw terminal |
|
R7ML-EC8A |
8-point extension transistor output (NPN) |
M3 screw terminal |
|
R7ML-EC16A |
16-point extension transistor output (NPN) |
M3 screw terminal |
|
R7ML-EC8B |
8-point extension transistor output (PNP) |
M3 screw terminal |
|
R7ML-EC16B |
16-point extension transistor output (PNP) |
M3 screw terminal |
|
R7ML-EC8D |
8-point extension transistor output (PNP, shortcircuit protection) |
M3 screw terminal |
|
R7ML-EC16D |
16-point extension transistor output (PNP, shortcircuit protection) |
M3 screw terminal |
R7K4FML Series
|
MODEL |
FUNCTION |
POWER / I/O CONNECTION |
|
R7K4FML-6-DA32 |
32-point contact input (NPN/PNP) |
M3 screw terminal |
|
R7K4FML-6-DCA32A |
16-point transistor output (NPN) / 16-point contact input (NPN/PNP) |
M3 screw terminal |
|
R7K4FML-6-DC32A |
32-point transistor output (NPN) |
M3 screw terminal |
|
R7K4FML-6-DC32B |
32-point transistor output (PNP) |
M3 screw terminal |
R7K4DML Series
|
R7K4DML-B-DAC32A |
16-point contact input (PNP) / 16-point transistor output (NPN) |
Tension clamp terminal / e-CON connector |
|
R7K4DML-B-DAC32B |
16-point contact input (NPN) / 16-point transistor output (PNP) |
Tension clamp terminal / e-CON connector |
|
R7K4DML-B-DAC32C |
16-point contact input (NPN) / 16-point transistor output (NPN) |
Tension clamp terminal / e-CON connector |
|
R7K4DML-B-DAC32D |
16-point contact input (PNP) / 16-point transistor output (PNP) |
Tension clamp terminal / e-CON connector |
R7G4HML Series
|
R7G4HML-6-SVF4 |
4-point high speed DC voltage/current input (isolated) |
M3 screw terminal |
|
R7G4HML-6-YVF4 |
4-point high speed DC voltage output (isolated) |
M3 screw terminal |
Features
-
Compact, all-in-one modules
-
A wide variety of sensor signal inputs
-
Removable terminal blocks make the module replaceable without disconnecting wiring.
-
Discrete I/O module can be attached to base analog module (R7ML Series)
