PRT12-2DO
- Sensing side diameter : M12
- Sensing distance : 2mm
- Installation : Flush
- Standard sensing target : 12×12×1mm(iron)
- Response frequency : 1.5kHz
-
Data sheet
Wire type and power DC 2-wire type 12-24VDC
Sensing side diameter M12 Sensing distance 2mm Installation Flush Standard sensing target 12×12×1mm(iron) Response frequency 1.5kHz Current specification Leakage current: Max. 0.6mA Control output Normally Open Material Case/Nut: Nikel plated Brass, (connector case of DIA. of sensing side Ø 8 mm: SUS303),
washer: Nikel plated Iron, sensing side: polybutylene terephthalate,
standard cable (black): polyvinyl chloride (PVC),
oil resistant cable (gray): oil resistant polyvinyl chloride (PVC)Cable Standard/material Standard cable Protection structure IP67(IEC standard) Body length Standard type Environment_Ambient temperature -25 to 70℃, storage: -30 to 80℃ Environment_Ambient humidity 35 to 95% RH, storage: 35 to 95% RH Hysteresis(distance) Max. 10% of sensing distance Residual voltage Max. 3.5V Weight Approx. 84g(approx. 72g)
