ALLEN BRADLEY 1794-OV16 Digital Output Module MALAYSIA
Description: The Allen-Bradley 1794-OV16 module is a Flex I/O 1794 series digital output module. It comes with 16 outputs which are sinking outputs that are rated at 24 Volts DC voltage. The 1794-OV16 digital output module is an open module with an IP 20 environmental protection rating. It can be mounted on a DIN Rail. The 1794-OV16 digital output module operates with 10 to 31.2 Volts DC of on-state output voltage.
Technical Specifications for 1794-OV16
|
Manufacturer |
Rockwell Automation |
|
Brand |
Allen-Bradley |
|
Part Number/Catalog No. |
1794-OV16 |
|
Product Type |
Flex I/O Digital Sinking Output Module |
|
Outputs |
16 Sinking |
|
On-state Voltage nom. |
24V DC |
|
Output Current Rating |
8.0A |
|
Off-state Voltage max. |
31.2V DC |
|
On-state Current max. |
500mA per Channel |
|
Off-state Leakage |
0.5mA max. |
|
On-state Voltage Drop max. |
0.2V DC max. |
|
Flexbus Current |
80mA |
|
Power Dissipation |
4.2W @ 31.2V DC |
