-High flow rate
-Damped operation
-Clear compact design
-Solenoid interchangeable without tools (Click-on®)
-Particularly suitable for use as water valve in accordance with DIN EN 60730-2-8

Technical Details

Medium	Gases, Liquids
Operating Temperature	-10 ... 50 °C, 14 ... 122 °F
Operating Pressure	0.1 ... 10 bar, 1.45 ... 145 psi
Port Size	G1-1/4
Actuation	Solenoid pilot / Spring return
Coil Code	9101
Function	NC
Nominal Diameter	32 mm
Valve operation	2/2
CV Body	26.6 cv
Flow	383 l/m, 13.5 scfm
Materials - Body	Brass
Materials - Elastomers	Nitrile rubber (NBR)
Certification - IP Rating	IP65
Dimensions - Height	92 mm
Dimensions - Length	124.5 mm
Dimensions - Width	132 mm
Weight	3.182 kg
Country of Origin	Germany, United States, India
Range	82400
Brand	IMI Buschjost
